Fine Adjust Applicator for MX150 ISO (M3) Blade Terminals
PARTS LIST
FineAdjust Applicator 63901-8600
Item
Order No
Engineering No.
Description
Quantity
Perishable Tooling
63901-8670 63901-8670 Tool Kit (All “Y” Items) REF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
63457-0070 63457-0070 Conductor Punch 1 Y
63455-0096 63455-0096 Conductor Anvil 1 Y
63454-0114 63454-0114 Insulation Punch 1 Y
63456-0078 63456-0078 Insulation Anvil 1 Y
63443-0037 63443-0037 Cut-Off Plunger 1 Y
63443-0038 63443-0038 Front Plunger Retainer 1 Y
Other Components
11-18-4094 60709A111 Feed Guide 1
63443-0009 63443-0009 Scrap Chute 1
63443-0024 63443-0024 Key 1
63443-0090 63443-0090 Wire Stop 1
63443-1716 63443-1716 18.60mm Height Spacer 1
63443-2202 63443-2202 2.00mm Coarse Spacer 1
63443-2209 63443-2209 9.00mm Coarse Spacer 1
63443-2301 63443-2301 3.05mm Fine Spacer 1
63443-2804 63443-2804 Front Plunger Striker 1
63443-2915 63443-2915 Striker Plunger 1
63443-6115 63443-6115 Rear Cover 1
63600-1057 63600-1057 Striker Plunger Spring 1
63700-0539 63700-0539 Cut-off Plunger Spring 1
63867-3007 63867-3007 Bottom Cap 1
Frame
63800-4901 63800-4901 Top 1
63801-3281 63801-3281 Base 1
63801-4650 63801-4650 Track 1
63459-0001 63459-0001 Terminal Track 1
Hardware
N/A N/A M3 by 6 Long SHCS 2**
N/A N/A M3 by 6 Long FHCS 1**
N/A N/A M4 by 6 Long SHCS 2**
N/A N/A M4 by 8 Long Flat Point SSS 1**
N/A N/A M4 by 12 Long SHCS 2**
N/A N/A M4 by 12 Long BHCS 2**
N/A N/A M4 by 16 Long SHCS 1**
N/A N/A M4 by 50 Long SHCS 2**
N/A N/A M5 by 12 Long SHCS 1**
N/A N/A #10-32 by 3/8”Long Flat Point SSS 1**
N/A N/A #10-32 Hex Jam Nut 1**
** Available from an industrial supply company such as MSC (1-800-645-7270).
Doc No: ATS-639018600
Revision: A
Release Date: 03-11-11
Revision Date: 03-11-11
UNCONTROLLED COPY
Page 3 of 5
